PoE modules are hardware components specifically designed to implement or support Power over Ethernet (PoE) technology. With PoE, devices such as network cameras, IP phones, and IoT sensors no longer require separate power cables, as a single Ethernet cable can simultaneously provide both power and network connectivity. PoE modules are the dedicated hardware units responsible for enabling this dual functionality. These modules typically exist in various forms and serve different purposes depending on their application scenarios.
Common forms and uses include:
This is the most common type. It is directly integrated inside the network device that requires power (such as a camera). It separates the DC power from the connected Ethernet cable and converts it to the voltage needed by the device's internal circuits (such as 12V or 5V), while passing the data signal to the device's network processing part. Essentially, it is a power adapter inside the device, except that the power is input through the network cable.
Integrated inside a PoE switch or PoE injector. It injects direct current from an external power adapter or the internal power supply of the switch into the idle pairs or data pairs of the Ethernet cable to be used for data transmission (depending on the PoE standard and cabling). Essentially, it is a circuit module that adds power to the network cable.
An independent small device (commonly known as Midspan or PoE Injector) is inserted between a non-PoE switch and the device that requires PoE power supply. It acquires power from a power socket and injects it into the cable leading to the powered device through the network cable. Data is transmitted normally from the non-PoE switch. Essentially, it is an independent power supply module that adds PoE functionality to a single network cable.
A small independent device is inserted between a PoE-enabled network cable (from a PoE switch or injector) and a device that does not support PoE but requires network connection. It separates the power and data in the input PoE network cable. The data is transmitted to the device through another network cable, while the power is output through a separate power socket (the device still needs to use its own power adapter). Essentially, it extracts the power from the PoE network cable for the device to use while ensuring normal data transmission. The application scenarios include providing power to old network devices that do not support PoE (such as some printers, non-PoE cameras), or powering development boards like Raspberry Pi.
For instance, the PoE HAT for Raspberry Pi. It is a small board that attaches to the development board through a specific interface. It acquires PoE power from the connected network cable, converts it to the voltage required by the development board (such as 5V), and powers the development board. Data is normally transmitted to the network interface of the development board. Essentially, it is an external module that adds PoE power receiving capability to devices that do not support PoE themselves.
The modules that can be integrated into industrial equipment cabinets. They offer centralized PoE power supply management or add PoE power receiving capabilities to industrial equipment. They are modular industrial-grade PoE power supply solutions.
Power Sourcing Equipment (PSE): Safely coupling power to the Ethernet cable used for data transmission.
Powered Device (PD): Safely separating the DC power from the Ethernet cable that transmits both data and power, and providing power to the device.
The main advantages of PoE modules/technology are as follows:
Simplified cabling: Only one network cable is needed to simultaneously solve power supply and networking issues, significantly reducing the number and complexity of cables.
Cost reduction: Saves costs on power cables, socket installation, and cabling.
Flexible deployment: Devices can be installed in locations far from power sockets (such as ceilings, outdoors, or corridors), not limited by power socket locations.
Safety: PoE standards include detection and protection mechanisms to prevent damage to non-PoE devices.
Centralized management: PoE switches can remotely control or monitor the power supply status (on/off) of ports. Therefore, PoE modules refer to various hardware components that realize the key function of Ethernet power supply, and they are the foundation for building modern PoE network infrastructure.
